Description
MEC is a configurable power distribution module developed mainly for the agriculture, construction, heavy duty and off-road applications. Because of the body layout and the PCB usage, the circuit diagram can be configured according to the customer needs.
There are 4 customization levels:
Soft | Medium | Medium* | High | |
Fuses/Relays | ˅ | ˅ | ˅ | ˅ |
Type and number of contents (mask) | – | – | ˅ | ˅ |
PCB | – | ˅ | ˅ | ˅ |
external connections (studs & connectors) | – | – | – | ˅ |
˅… means customizable component
-… default component |
MAIN FEATURES:
• Press-fit technology.
• A Gore-Tex vent provides a barrier against water and dust
and allows the free circulation of air, avoiding the formation of
moisture.
• MEC 97 can be fixed in flat, inclined or vertical position.
• Appropriate latches preload the cover against the seal and close
the MEC.
• The cover is tethered to the body to ensure it won’t be displaced.
• Anti-vibration system integrated inside the fixing points.
optional: CAN BUS Module
